| 产品特性：220V输入 | 是否进口：否 | 产地：山东 |
| 品牌：美积奥 | 型号：MP120-S13.8 | 适用范围：5V 13.8V |
| 电源名称：浮充备电 | 输出电流：0-10A | 输入电压：220/110V |
| 输出电压：12V 24VV | 输出功率：200W | 频率范围：100KHZ |
| 加工定制：是 |
120 w 单路电源 Single Output DIN Rail Power
输入电压 AC input voltage range ........... 300-480VAC
输入频率 Input frequency ........................47~63Hz
突入电流 AC Inrush current......................cold start,40A at 230V
电压调整率 Line regulation(full load).........≤ 0.5%
负载调整率 Load regulation......................±1%
纹波及噪声 Ripple & Noise.......................≤ 1% (20MHZ Band Width)
过载保护 Output overload protection........110~150%
过压保护Output over voltage Protection....115~150%
绝缘耐压 Withstand voltage.........................I/P-O/P:3KVAC/1min
I/P-F/G:1.5KVAC/1min
O/P-F/G:0.5KVAC/1min
工作温度 Working temperature......................-20°C~+60°C
无故障工作时间 MTBF...................................100.000 hours
安规标准 Safety standards.............................UL508,EN60950
EMC标准 EMC standards..............................EN55022 Class B
EN61000-3-2,3 EN61000-4,2,5
